Setup menu
G&D HK-Controller 20 · 8
Testing the panel button’s function
On the
Show Input Status
menu, you can test the functions of the panel button.
If the panel is properly connected, the active channel is shown in square brackets
when pressing a button.
The following screenshot shows the menu when pressing buttons 1, 9, 17 and 18:
NOTE:
Pressing several buttons at the same time marks all active inputs.
