3.2 Set to factory default
3.4 Standalone mode
3.3 DMX Addressing
Enter DMX address by means of the keys "+" and "-". Confirm a store by pressing
key "Enter".
To set back the VaryLED 3*84 to factory setting press key "Menu" one time.
will be displayed. Press key "Enter" to enter Factory
default menu. Select and press key "Enter".
will be displayed. Confirm by pressing key "Enter" again. The personal setting
of the V
3*84 will be set back to factory default.
If the white balance was adjusted before, it will be not affected by the set back to
factory default.
FACTORY DEFAULT
LOAD DEFAULTS SURE ?
aryLED
A sequence consisting of preprogrammed cues can be recalled by means of the
Standalone mode. The sequence will run as a loop. Cues can be entered in two
different ways. The first way is to program every feature by means of the key of
the units own control panel. The second way is to program the cues by means
of a connected DMX control console and to store them onboard of the VaryLED.
Enter DMX values by means of the control panels keys:
Recall standalone mode:
Press key "Menu" first. Then press key "+" five times (see page 24),
STANDALONE STEPS will be displayed. Confirm by pressing key "Enter"
STEP NR. 1/1, will be shown. Confirm again by pressing "Enter"
After this second confirmation the display will show: MODIFY 1/1
Now recall Modify menu by pressing key "Enter".
The Modify menu enables access to all parameters of the unit. Use key "+" and "-"
to recall the desired parameter. Confirm choice by pressing "Enter". Enter DMX
values by means of the keys "+" and "-". Store DMX values by pressing "Enter".
To escape press key "Menu".
Add one step to the sequence:
Press key "+" until menu is shown. Confirm by pressing key "Enter".
will be displayed. Confirm by pressing key "Enter" again.
A new step will be added to the sequence.
INSERT
SURE ?
The DMX values of the last step will be automatically copied to the new step.
To alter DMX values enter Modify menu and proceed like describe in chapter:
“Enter DMX values by means of the control panel keys.”
