Activate the standalone mode:
The standalone mode is activated in the menu: DMX/STANDALONE
independent if it was programmed manually or by a connected DMX board.
To enter menu DMX/STANDALONE press key "Menu" and afterwards key "+"
three times. You will find To confirm press
"Enter". Select standalone-function by pressing key "+" and press "Enter" one
time to activate.
will be shown on the display.
DMX/STANDALONE displayed.
S-ALONE: 1 / 2
Deactivate the standalone mode:
To deactivate standalone mode press "Enter" and key "-" one time. The display
will show:
Press key "Enter" again and find
displayed Escape by pressing key "Menu".
DMX MODE. DMX/STANDALONE
.
3.5 Compressed Mode
In order to operate the VaryLED with less DMX-channels you can change the
DMX-Mode of the VaryLED to
. In this mode the channels
colour macro, colour wheel, pan/tilt speed, effect speed and blackout move are
deactivated.
That means the colours can be operated by the RGB channels only. (See
page 28 DMX protocol). Open menu point
and confirm it with
"Enter". Push "+" two times, the display will show . Confirm it with
"Enter" and push "+", now the display shows . Confirm it
by pressing "Enter".
COMPRESSED MODE
PERSONALITY
DMX MODE
COMPRESSED MODE
3.6 Camera Mode
For flicker free recording in TV-studios the VaryLED 3*84 offers two different modes
from 50Hertz (PAL, Secam) to 60 Hertz (NTSC). Access the menu point
and confirm it with “Enter”. Push “+” three times, the display will show
.
Confirm it with “Enter”. Now choose the needed frequency with the buttons “+” and “ -”,
confirm it with “Enter”.
PERSONALITY
CAMERA MODE
