Updating the fixture:
" enu"
There will be a message on the monitor
displaying a connected fixture and an additional menu will be shown.
.
1. Disconnect fixture from mains and remove both DMX cables.
2. Connect the upgrade-Dongle to the fixture (use the DMX cable which comes
together with the dongle only! Upgrade-Dongle DMX-out / fixture: DMX-in)
Connect the USB cable with the USB port of your computer.
3. Recall the program-start of you computer and select the program for the
Upgrade-Dongle.
4. Press M key of your fixture and hold it.
5. Connect the fixture to mains again.
6. Choose the desired file on your computer.
7. Start the update procedure by selecting "open"
8. After completing the update the message "Update complete" will be displayed on
the computer and the fixture will reset.
There might be a message "Driver not digitally signed" show on your computer
monitor, if the driver is installed on OS Windows XP.
Complete the installation anyway, because the driver will work with the
Upgrade-Dongle without problems.
5.3 Software update
Installation of the software:
1. Insert the floppy disc into floppy-disc drive of your computer
2. Use the explorer to open drive A:
3. Open file: Setup.exe (double-click)
4. That starts up the installation program --> follow the on-screen instruction to
complete the installation of the program file.
To update the fixture a Upgrade-Dongle with the fitting software is required.
Before using the upgrade-dongle install the software on your computer.
The procedure of the software installation differs according to the OS.
Follow the procedure below to install the software on your machine. The example
below might be a little bit different to the way the OS in your computer works.
The software works with Windows 98, 2000 and XP.
Installing the driver:
1. Connect the upgrade-Dongle with the USB port of your computer.
2. The installation program will be activated -->follow the on-screen instruction
to continue the installation.
3. IMPORTANT:
Select: install driver manually, because automatical driver-installation will not
work in most cases.
4. After choosing "manual installation", select drive A:\Driver
5. Confirm selected driver and complete installation.
