Reset DMX values of a step:
To reset the DMX values of a step proceed as follows:
Press key "Menu" one time. Then press 5 times key "+" -
will be shown on the display. Confirm by pressing key "Enter".
will
be displayed. Recall the desired step by means of the keys "+" and "-", confirm
the selection by pressing key "Enter". Select function
by means of
the keys "+" and "-". After selecting the function press key "Enter". will be
displayed. Confirm selection by pressing key "Enter" again. The DMX values of the
selected step will be set to zero.
STANDALONE STEPS
STEP NR. 1/X
RESET STEP
SURE?
Store cues from a DMX board:
Select the Standalone menu:
Press key "Menu" first and then press key "+" five times.
will
be displayed. Confirm selection by pressing key "Enter". Then press key "+" one time
to enter capture function.
will be displayed. Press "Enter" to enable
the fixture to receive DMX data from a connected DMX board. The display will show
To store data press "Enter" again. The display will show:
To insert a new step press key "+". The display will show:
Press "Enter" to confirm and the display will show:
To continue programming press key "-" one time and find: shown on
the display. Press "Enter" to enable fixture to receive DMX data, and see confirmation
on the display. Repeat the process of storing data on the fixture by
pressing "Enter" again.
(Press "Enter" first time:
; Press "Enter" second time:
To continue, insert a new step and repeat process.
STANDALONE STEPS
CAPT DMX 1/ 1
DMX CAPTURE.
CAPT DMX 1/1.
SURE?
INSERT 2/2.
CAPT DMX 2/2
DMX CAPTURE
START CAPTURE CAPT DMX
X / X).
Delete one step of a sequence:
Recall the Standalone menu. must be shown on the display.
Confirm by pressing key "Enter". will be displayed.
STANDALONE STEPS
STEP NR: 1/X
Use keys "+" and "-" to recall the desired step. Confirm selection by pressing key
"Enter". Select menu
by pressing key "+". Confirm the selection of the step
by pressing key "Enter". will be displayed. Now confirm again by pressing
key "Enter" and the selected step will be deleted.
DELETE
SURE?
