Technical data
G&D TradeSwitch8-USB · 35
English
Technical data
TRADESWITCH8-USB
Console
Connections per device: 1
Connection:
directly at the device
Interfaces
for console
USB keyboard/mouse:
2 × USB-A socket
USB 2.0 (transparent):
2 × USB-A socket
Audio:
1 × 3,5-mm phone jack (Speaker),
1 × 3,5-mm phone jack (Line In)
Computer
Connections per device: 8
Connection:
with supplied cables at the device
Interfaces
per computer
USB:
1 × USB-B socket
Audio:
1 × 3,5-mm phone jack (Line In),
1 × 3,5-mm phone jack (Line Out)
TradeSwitch LED:
1 × D-Sub9 socket
Audio
Type:
analog
Band width:
22 kHz
Update
Mode:
local service socket
Interface:
2,5-mm phone jack
Power supply
Type:
internal power pack
Connection:
IEC plug (IEC-320 C14)
Power input:
100mA@240VAC; 190mA@100VAC
Power input
Standby:
3,7 W @ 240 VAC; 2,9 W @ 100 VAC
Operation:
11,6 W @ 240 VAC; 11,2 W @ 100 VAC
Casing
Material:
anodised aluminium
Dimensions (w × h × d):
435 × 44 × 210 mm
Weight:
approx. 2,1 kg
Operation
environment
Temperature:
+5 to +45 °C
Humidity:
< 80%, non-condensing
Conformity
CE, RoHs
