Guntermann & Drunck UCON-Audio-s - Handbuch (Seite 28)

Technical data
11 · G&D UCON-Audio-s
Technical data
Video Signal type: analog video
Resolution:
(local connection)
max. 1920 x 1200 @ 60 Hz
(depending on cable length)
Audio Resolution: 24 bit
Sample rate: 48 kHz
Bandwidth: 20 kHz
Transmission Distance between user module
and target module:
max. 300 m
Transmission type to user module: dedicated CAT-x link
Delay compensation:
yes
User modules Number: 1
Occupied user module connec-
tions at matrix switch:
1
Additionally connectable local
computers:
2
Main power
supply
Type: internal power pack
Connection: IEC plug(IEC-320 C14)
Voltage: AC100-240V/60-50Hz
Redundant 
power supply
Type: external power pack
Connection: miniDIN-4 power socket
Voltage: +12VDC
Casing Material: anodised aluminium
Dimensions (W x H x D):  Desktop: 270 x 44 x 210 mm
 Rackmount: 19” x 1 HU x 210 mm
Weight: approx. 1,4 kg
Operating
environment
Temperature: +5 to +45 °C
Air humidity: < 80%, non-condensing
Interfaces for user module: 1 x SubHD15 socket (video)
2 x PS/2 socket (keyboard/mouse)
2 x USB-A socket (keyboard/mouse)
to matrix switch: 1 x RJ45 socket
for local computers
(with user module CATpro2)
2 x RJ45 socket
for update: 1 x 2,5 mm jack plug
Conformity CE, RoHs
