Guntermann & Drunck DVISplitter2-DL - Handbuch (Seite 15)

»DVISplitter2-DL«
G&D DVISplitter2-DL · 2
»DVISplitter2-DL«
DVISplitter2-DL distribute and extend video images to two monitors.
The video data coming in at the DVISplitter2-DL is transmitted to the connected
monitors. Resolution and colour depth at the monitors match the features of the
incoming signal.
Supported transmission lengths
An overview of supported DVISplitter2-DL transmission lengths is given on page 8.
Most recent graphics cards generate high quality video data, which can be transmit-
ted over certain distances without any loss of quality.
Some graphics cards, however, do not reach the given transmission lengths. Among
these are graphics cards with the following chipsets:
 ATI Radeon X300
 Intel GMA950 (Mac mini)
 Matrox Millenium G450
Package contents
 1 × DVISplitter2-DL
 1 × Portable power pack 12V/2A
 1 × IEC cable
 1 × video cable DVI-D-DL-M/M-2
 1 × Installation Guide
ADVICE: Connect other identical devices to the DVISplitter2-DL to connect more
monitors and/or increase the distance to be bridged.
NOTE: Image data of such graphics cards is only partially suited for transmissions
over large distances.
