Technical data
G&D DVISplitter2-DL · 8
Technical data
DVISPLITTER2-DL
Supported
video data
Resolution:
max. 2560 × 1600 @ 60 Hz
Colour depth:
24 bit
Video input:
1 x DVI-D (Dual Link)
Video outputs:
2 x DVI-D (Dual Link)
DDC:
DDC information at
»DVI-D DL Out 1« interface
Cable lengths
Between video source and splitter: 2 meters
Between splitters:
2 meters
Cascading
Cascade levels
3
Power supply
Type:
Portable power pack (12V/2A)
Connector:
Mini-DIN 4 socket
Power input:
12VDC/200 mA
Current
consumption
Standby:
40 mA
Operation:
180 mA
Housing
Material:
Anodised aluminium
Dimensions (W x H x D):
105 × 26 × 84 mm
Weight:
Approx. 200 g
Operational
environment
Temperature:
+5 to +40 °C
Air humidity:
< 80%, non condensing
Conformity
CE, RoHs
NOTE:
The cable lengths and the number of cascade levels depend on the quality
of the incoming video signal.
Tests with different video sources generated varying results regarding the quality
of the video signal and the resulting cable lengths and cascade levels.
The stated data are empirical values that were reached by most of the tested
graphics cards.
