Setup menu
G&D OperatorPanel · 7
How to select the bit rates of the RS232 interface:
1. Start the terminal emulator.
2. Load the connection settings of the setup menu and establish the connection.
3. Use the Arrow or Arrow keys to select Bitrate RS232 Port .
4. Press Space (repeatedly) to choose between the following options:
5. Press S to save the values.
6. Press Q to return to the main menu.
Safety Switching
To switch to a channel, press and hold the Enable button and press the Select button
to switch to the desired channel.
Pressing and holding the Enable button prevents you from switching between chan-
nels by accident.
You can disable the Safety Switching function (see page 7) if you only want to use a
Select button to switch between channels
How to enable/disable »Safety Switching«:
1. Start the terminal emulator.
2. Load the connection settings of the setup menu and establish the connection.
3. Use the Arrow or Arrow keys to select Safety Switching .
4. Press Space to disable ( Off ) or enable ( On ) the function.
5. Press S to save the values.
6. Press Q to return to the main menu.
 9.600  19.200  38.400
 57.600  115.200 (Standard)  230.400
