Guntermann & Drunck GmbH HardBoot CCX
Installation and Configuration Manual
Page 7
Slave No. DIP-
Switch 1
DIP-
Switch 2
DIP-
Switch 3
DIP-
Switch 4
1 Off Off Off Off
2 On Off Off Off
3 Off On Off Off
4 On On Off Off
5 Off Off On Off
6 On Off On Off
7 Off On On Off
8 On On On Off
9 Off Off Off On
10 On Off Off On
11 Off On Off On
12 On On Off On
13 Off Off On On
14 On Off On On
15 Off On On On
16 On On On On
Off:
Switch in up position
On: Switch in down position
3. Plug the two power cables into separate grounded power outlets.
LED-indicators A and B light up when power is connected.
