Guntermann & Drunck GmbH HardBoot CCX
Installation and Configuration Manual
Page 10
The following example illustrates this description:
Connection between CATCenter Master and CATCenter Slave
2.4 Connecting a target to another HardBoot CCX
You can connect a target originally connected to one HardBoot CCX to another
HardBoot CCX later. In this case, you have to modify the power supply
switching configuration (see
Chapter 3 ) to match the new connection(s).
However, if you connect the target to a different CATCenter device you must
 connect this target including the CAT
PRO
2 dongle to a free CPU port
on the new CATCenter
 associate the target with a HardBoot CCX connected to this
CATCenter
 specify the new connection in Power Management (see Chapter 3 )
Slave number 1 Slave number 1
Slave number 2 Slave number 2
CATCenter Master CATCenter Slave
