Guntermann & Drunck GmbH HardBoot CCX
Installation and Configuration Manual
Page 14
The physical ID of the CATCenter (not editable) is shown in the third line of the
left column and the right column shows the current description (see
Chapter
5.8.7 of the CATCenter Operation Guide ).
All yellow entries in the list field are only editable when a HardBoot has been
recognized on the CATCenter.
In the column 'HardBoot', you define to which HardBoot the selected target is
connected. The following selections are available:
 None No HardBoot is connected
 1 – 16 Numbering of each of the available HardBoots Up to 16
HardBoot CCX can be cascaded; each is assigned an
address by means of DIP-switches.
In the column 'PORT', you define on which CPU-Port the selected target is
connected to the HardBoot. The following selections are available:
 None No HardBoot is connected
 1 – 8 CPU port numbering on the HardBoot. The first CPU port on
the HardBoot is thus number 1, the second number 2, and so
forth.
To save the settings leave the menu by pressing the
F2 key. Use the ESC key
to cancel the current changes. In both cases, you return to the POWER
MANAGEMENT submenu.
