Rear Connector Pin Assignments SIM77PV4
a c
1 VCC in (+5V) VCC in (+5V)
2
3
4 MOD in
5
6 PZF in
7
8
9
10 +SIM_OUT1
11
12 10MHz in -SIM_OUT1
13
14
15
16 +SIM_OUT2
17
18 -SIM_OUT2
19
20
21
22 +SIM_OUT3
23
24 -SIM_OUT3
25
26
27 7,75MHz in
28 +SIM_OUT4
29
30 -SIM_OUT4
31
32 GND GND
male connector according to DIN 41612, type C 64, rows a + c
Steckerleiste nach DIN 41612, Typ H 15 M
