Technical data
Assembled dimensions: approx. 57 x 86 x 48 cm
Grill:
approx. Ø44 cm
Weight:
approx. 5.7 kg
Holding capacity:
approx. 1,5 kg
Required tools
Cross-tip screwdriver
Open-jawed spanner
7mm, 10mm and 13mm
Assembly preparations
1. Please read the assembly instructions carefully
all the way through, and follow the safety
instructions.
2. Allow yourself sufficient time for assembly.
3. Establish a level work surface beforehand of
approximately two to three square meters.
4. Remove the device from the packaging!
5. Organize the parts and the required tools so
that they are close at hand.
6. Please use the list and drawing below to verify
that you have all of the parts.
Part list
Designation
Qty.
A. Handle
3
B. Vent plate
2
C. Hood
1
D. Hood holder
1
E. Grill element
1
F.
Charcoal grate
1
G. Fire bowl
1
H. Stand reinforcement
3
I.
Wheel stand
2
J.
Ash collection sheet holder
3
K. Wheel
2
L. Wire shelf
1
M. Stand cap (pre-mounted)
1
N. Ash collection sheet
1
O. Stand element
1
P.
Charcoal divider
2
