1. Installation
RO
i
880 A/C/K/R - RO
i
889 B/C/K
G
B
Fig. 5
1. Installation of height-adjustable hitches
1.
Check the anti-slip lock if present.
2. Trailer hitches (such as bolt, ball hitches or PitonFix) are inserted
into the guide rails from above.
Attention: hold the hitch tight!
x
Push the handle (H) of the height adjustment first back and then to
the left. The stop bolts (A) move inwards (see Fig. 5).
x
Insert the hitch into the ladder at the desired height.
x
Press the handle (H) of the height adjustment to the right.
x
The stop bolts (A) move outwards.
x
Only when the stop bolts (A) are fully engaged can the handle be
moved back to the front into the starting position.
Check: In the secured position, the handle (H) can only be pushed
about 4 mm to the left.
Operation and maintenance of the hitches are carried out in
accordance with the supplied installation instructions.
Fig. 4
