3. Technical data RO
i
880 A/C/K/R
Article no. . Version Fastening Track width ABG EG D-value Vertical load (t)
RO (Sw) (mm) M) e1 (kN) (up to 40 km/h)*
880A08042 lang 6-Loch 330 4776 0149 89,3 2/3*
880A09142 kurz 4-Loch 330 4776 0149 89,3 2
880C0114 C lang + Piton 6-Loch 330 4776 0149 89,3 2/3*
880K0114 C lang + Kugel 6-Loch 330 4776 0149 89,3 2/4*
880R 3304 C lang + Rahmen 6-Loch 330 4776 0149 89,3 2/4*
889B 3504 C lang + Auflage 8-Loch 390 10089 0564 100 2/4,5*
889C 3514 C lang + Piton 8-Loch 390 10089 0564 100 2/3*
889R 3534 C lang + Kugel 8-Loch 390 10089 0564 100 2/3,5*
820 L 3304 C Zugpendel mit Piton 9958 0432 89,3 4*
820 L 07340 Zugpendel mit Kugel 9958 0432 89,3 3*
825 L 3334 C Zugpendel mit Piton 9958 0432 89,3 4*
825 L 07341 Zugpendel mit Kugel 9958 0432 89,3 3*
820 L 3534 C Zugpendel mit Piton 9901 0407 100 4*
825 L 3434 C Zugpendel mit Kugel 9901 0407 100 4,5*
801 L 3504 C Zugpendel 9804 0345 89,3 1– 3*
The permitted vertical load for all ladders above the power takeoff shaft is 2 t; under the PTO shaft they can be operated with 3 – 4.5 t depending on the version. In the lad-
der 880A08 the piton used (820A + 820B) and the ball (825A + 825B) can be operated under the PTO shaft with 3 t vertical load. In the ladder 889B35 with support, the
inserted drawbars with piton/ball can be loaded with 4 t / 4.5 t vertical load. In the drawbar 801L35 that can be inserted into the ladder 889B35, the vertical load depends
on the free length (261, 321, 391 mm).
Attention:
Observe the D-value and the vertical load of the towing hitches used with the ladders.
The ball 80 may only be coupled with ROCKINGER or other approved ball hitches in accordance with ISO 24347 which are suitable for securing connection and locking
and which guarantee the necessary swivel angle of + / – 60h in horizontal and + / – 20h in the vertical and axial direction.
!
