MAX100 INBETRIEBNAHME
6/9/00
Command THC (X-Y)
Betriebsanleitung
3e-5
Abbildung 3e-2
MAX100-Stromquellen-Interface-Kabelanschlüsse
A
B
Plasma Start
Plasma Start
24V -
24V +
5
4
3
2
1
J4
TB1
35
36
33
34
C
34
33
35
36
C
C
4
3
2
1
J3
Pilot Arc-
Pilot Arc+
Transfer IN-
Transfer IN+
THC.77
Plasma-Interface-Baugruppe
Plasmastart -
Plasmastart +
24V -
24V +
Pilotlichtbogen -
Pilotlichtbogen +
Transfer Ein -
Transfer Ein +
