Hypertherm MAX200 Machine Torch Plasma Arc Cutting System Benutzerhandbuch
Seite 109
12/10/99
STANDARD-KOMPONENTEN
MAX200
(Handbrenner) Betriebsanleitung
6-15
Hintere äußere Wand – MAX200 Stromquelle
Teile-
Position
nummer
Beschreibung
Kennzeichnung
Menge
129252
Pump Motor Subassembly
1
1
128385
Kit, Replacement Motor, 1/3 HP
M1
1
2
128384
Kit, Replacement Pump, 70 GPH
1
3
031122
Drive Coupling, Pump to motor
1
129383
Valve Subassembly (w/ elec connectors)
1
4
006046
Valve, Sol 240V 3/8 NPT NC
V7
1
029361
Flowswitch Subassembly (w/ elec connector)
1
5
005119
Flowswitch, 0.5 GPM
FS1
1
6
006053
Valve, Check 1/3 PSI, 1/4 NPTM
1
7
027136
Heat Exchanger, Water/Air
MX1
1
8
027139
Filter Housing, 10" X 3/8 NPT
1
9
027005
Filter, Element
1
10
011025
Filter Regulator
1
11
011027
Gauge, High Press (for 011025)
1
12
002304
Reservoir, coolant
1
13
022036
Gauge, liquid level
1
14
129618
Level Switch Subassembly, 1/2 NPT
LS1
1
15
029323
Temp Switch Subassembly, 162 Deg F
TS2
1
16
006099
Bib drain valve 1/4 NPT
1
