VARYSCAN 4 COMPACT PLUS 575 HMI
gobo 1 prism
DMX
072 -
080
gobo 2 white
DMX
081 -
089
gobo 2 artificial light filter
DMX
090 -
098
gobo 2 daylight filter
DMX
099 -
107
gobo 2 prism
DMX
108 -
116
gobo 3 white
DMX
117 -
125
gobo 3 artificial light filter
DMX
126 -
134
gobo 3 daylight filter
DMX
135 -
143
gobo 3 prism
DMX
144 -
152
gobo 4 white
DMX
153 -
161
gobo 4 artificial light filter
DMX
162 -
170
gobo 4 daylight filter
DMX
171 -
179
gobo 4 prism
DMX
180 -
188
gobo 5 white
DMX
189 -
197
gobo 5 artificial light filter
DMX
198 -
206
gobo 5 daylight filter
DMX
207 -
215
gobo 5 prism
DMX
216 -
255
if at DIP-switch No. 2 switch is "ON"
GOBO 5 prism
DMX
216 -
254
Reset
DMX
255
channel 4
dimmer / shutter
dimmer shutter closed --> blackout (BO)
DMX
000
dimmer 0 – 99%
DMX
020 -
127
dimmer open
DMX
128 -
137
dimmer shutter immediatelly closed
DMX
138 -
139
shutter sequence 1,00 flashes/sec
DMX
140 -
shutter sequence 11,00 flashes/sec
DMX
243
shutter open
DMX 244 - 255
channel 5
Pan movement 170°
channel 6
Tilt movement 90°
JB lighting 6 channel
channel 1
X-axis
channel 2
Y-axis
channel 3
gobo and effect wheel
channel 4
colour
channel 5
simmer shutter
channel 6 iris and goborotation
channel 1
Pan movement 170°
channel 2
Tilt movement 90°
channel 3
gobo and effektwheel
white
DMX 000 -
008
artificial light filter
DMX 009 -
017
daylight filter
DMX 018 -
026
prism
DMX 027 -
035
floodfilter
DMX 036 -
044
gobo 1 white
DMX 045 -
053
gobo 1 artificial light filter
DMX 054 -
062
gobo 1 daylight filter
DMX 063 -
071
gobo 1 prism
DMX 072 -
080
gobo 2 white
DMX 081 -
089
gobo 2 artificial light filter
DMX 090 -
098
gobo 2 daylight filter
DMX 099 -
107
gobo 2 prism
DMX 108 -
116
gobo 3 white
DMX 117 -
125
