VARYSCAN 4 COMPACT PLUS 575 HMI
gobo 3 artificial light filter
DMX 126 -
134
gobo 3 daylight filter
DMX 135 -
143
gobo 3 prism
DMX 144 -
152
gobo 4 white
DMX 153 -
161
gobo 4 artificial light filter
DMX 162 -
170
gobo 4 daylight filter
DMX 171 -
179
gobo 4 prism
DMX 180 -
188
gobo 5 white
DMX 189 -
197
gobo 5 artificial light filter
DMX 198 -
206
gobo 5 daylight filter
DMX 207 -
215
gobo 5 prism
DMX 216 -
255
if at DIP-switch No. 2 switch is "ON"
GOBO 5 prism
DMX 216 -
254
Reset
DMX 255
channel 4
colour
colour 0 (white)
DMX 000 -
007
colour 1
DMX 008 -
015
colour 2 (red)
DMX 016 -
023
colour 3
DMX 024 -
031
colour 4 (yellow)
DMX 032 -
039
colour 5
DMX 040 -
047
colour 6 (pink)
DMX 048 -
055
colour 7
DMX 056 -
063
colour 8 (green)
DMX 064 -
071
colour 9
DMX 072 -
079
colour 10 (orange)
DMX 080 -
087
colour 11
DMX 088 -
095
colour 12 (blue)
DMX 096 -
103
colour 13
DMX 104 -
111
colour 14 (dark-green)
DMX 112 -
119
colour 15
DMX 120 -
127
colour wheel rotation speed (slow)
DMX 128 -
colour wheel rotation speed (fast)
DMX
255
channel 5
dimmer / shutter
dimmer shutter closed --> blackout (BO)
DMX
000
dimmer
DMX 019 -
127
dimmer open
DMX 128 -
137
dimmer shutter immediatelly
DMX 138 -
139
shutter sequence 1,00 flashes/sec
DMX 140 -
shutter sequence 11,00 flashes/sec
DMX
243
shutter open
DMX 244 -
255
channel 6
iris and gobo rotation
iris closed / gobo first position
DMX
000
iris open / gobo first position
DMX
-
064
second gobo position
DMX
065
third gobo position
DMX
066
locked into position 180°
DMX
106
locked into position 360°
DMX
148
locked into position 540°
DMX
191
rotation left highest speed
DMX
192
rotation left lowest speed
DMX
222
rotation stop
DMX 223 -
224
rotation right lowest speed
DMX
225
rotation right highest speed
DMX 255
Occupation DMX-In / DMX-Out
