38
VARYSCAN 4 COMPACT PLUS 575 HMI
R34 120R 0,6W
R35 4R 1W
R36 1R 1W
R37 1R 1W
R38 36R 1W
R39 36R 1W
R40 1R 1W
C1 18pF C41 220nF
C2 18pF C42 2,2nF
C3 4,7uF/35V C43 100nF
C4 100nF C44 470uF/35V
C5 100nF C45 2,2nF
C6 22uF/35V C46 47u/35V
C7 100nF C47 220nF
C8 100nF C48 47u/35V
C9 100nF C49 220nF
C10 820pF C50 4700uF/35V
C11 820pF D1 LM336
C12 47uF/35V D2 Bridge
C13 220nF F1 Fuse
C14 220nF JP1 Header 4
C15 47uF/35V JP2 Header 4
C16 220nF JP3 Header 4
C17 220nF JP4 Header 4
C18 100nF JP5 Header 4
C19 3,3nF JP6 Header 2
C20 220nF P1 Connector DB15
C21 47uF/35V P2 Connector DB15
C22 220nF Q1 BC337B
C23 47uF/35V Q2 BC337B
C24 820pF Q3 BC337B
C25 820pF Q4 BC337B
C26 3,3nF Q5 BC337B
C27 47uF/35V Q6 BC337B
C28 220nF Q7 BC337B
C29 220nF Q8 BC337B
C30 220nF Q9 BC337B
C31 47uF/35V Q10 BC337B
C32 820pF Q11 BC337B
C33 820pF Q12 BC337B
C34 3,3nF Q13 BC337B
C35 220nF Y1 Quarz 16MHz
C36 220nF
C37 2,2nF
C38 47uF/35V
C39 220nF
C40 47uF/35V
