39
6.2.2. EXPOSURE
Exposure mode
• Auto Mode
Full Auto with Auto Iris, Gain and Shutter Speed. User can turn on/off AGC and Digital Slow Shutter feature.
• Shutter priority mode
User can set variable shutter speed, and Iris and AGC is set automatically according to the brightness of the
subject. Digital Slow Shutter can’t be used in this mode.
• Iris priority mode
User can set Iris Level, and shutter speed and AGC is set automatically according to the brightness of the subject.
User can turn on/off AGC and Digital Slow Shutter.
• Manual mode
User can set Shutter speed, AGC Gain in manual. User can also use Digital Slow Shutter by adjusting the shutter
speed.
NOTE: Refer to the Exposure Control in Command List for the value range of AGC Gain, Shutter Speed, Iris and
Exposure compensation.
Exposure compensation (Brightness)
• Function to offset the internal reference brightness level used in the AE mode, by steps of .5dB.
MODE Select auto focus mode
AUTO, ONE PUSH, MANUAL
DISTANCE
Select minimum distance in focus between camera and object
0. / .0 / .3 / .0 / 6.0 m
LENS REFRESH
Lens origin calibrated automatically
OFF/ON ( day ~ 0 days)
E.ZOOM
Select maximum digital zoom magnification
OFF/ON (max x ~ x9, x, x3, x5, x8, x3)
