40
Flickerless
• In this mode, the shutter speed is fixed to /00(NTSC) or /0(PAL) of the flashing period of the fluorescent
lighting to minimize the flicker.
MODE
Select exposure mode
AUTO / SHUT.P / IRIS.P / MANUAL
AGC
Select Auto Gain Control
• OFF/ON (AUTO, SHUT.P or IRIS.P Mode)
• 0//4/6/8/0//4/6/8/0//4/6/8/30dB (MANUAL Mode)
SHUT SPEED
Can be set in SHUT.P or MANUAL mode.
• NTSC: x5, x8, x64, x3, x6, x8, x4, x, /60, /90, /00, /80, /50, /500,
/000, /500, /000, /5000, /0000, /0000, /50000, /00000 sec
• PAL: x5, x8, x64, x3, x6, x8, x4, x, /50, /80, /0, /50, /50, /500, /000,
/500, /000, /5000, /0000, /0000, /50000, /00000 sec
NOTE: Slow shutter speed (x2 ~ x512) can be set in MANUAL mode.
IRIS
Iris level can be set in IRIS.P mode.
 ~ 8 steps
DSS
Select Max DSS (Digital Slow Shutter)
OFF / x, x4, x8, x6, x3, x64, x8, x5
FLICKERLESS
Select Flickerless mode
OFF/ON (remove screen flicker)
BRIGHTNESS
Adjust brightness level
 (dark) ~ 5 (bright) steps
WDR/BLC
The WDR function ensures that when images have been shot under conditions such as these,
the images free from loss of dark detail or overexposure will be output, and it achieves this by
combining a multiple number of images, shot at different exposure durations.
Select WDR (Wide Dynamic Range) or BLC (Back Light Compensation)
• OFF / WDR / BLC
WDR: Select level
 ~ 7 steps
BLC: The BLC function provides compensation by increasing the brightness of the overall
screen so that subjects being shot with a loss of dark detail due to backlight will have just
the right brightness level.
NOTE: Can’t use WDR and BLC at the same time.
(When WDR On, BLC is Off. And when BLC is On, WDR is Off)
NOTE: Both of WDR and BLC doesn’t work in Manual Exposure Mode.
Select area, level, mode
• Area ( ~ 9), Level (low / mid / high) and Auto / manual
