46
PRIVACY
POSITION: Adjust the mask position
SIZE: Adjust the mask size
MOTION DET
It instructs the camera to detect movement within the monitoring area and the send an alarm
signal automatically.
• You can set up to 3 MD Window.
• You can set MD Window for the detection range of (H) x 8(V) blocks. (Using Visca Command)
• When the motion is detected in the set frame, the Alarm activates through Alarm ACK and
MD-Out port.
• You can set the Zoom position (MD Zoom Preset) to move when the MD Alarm is activated.
• The interval of alarm detection and dwell time can be set up to 56 sec. in units of  sec.
Interval Time: The MD Alarm isn’t activated again till the interval time passed by.
Dwell Time: It keeps the MD Alarm Signal (MD-Out) and MD Zoom Preset Position during
the set dwell time, after the alarm activated.
MODE: MD function enable or disable (OFF/ON)
AREA#: Select MD area number (~3)
ACTIVATE: Activate or deactivate the each MD Area (OFF/ON)
SENSITIVITY: Adjust sensitivity of MD (~0)
INTERVAL TIME: Select the alarm interval time (~56sec)
DWELL TIME: Select the duration time about changing MD mode ( ~ 56sec)
POSITION: Adjust the MD position
SIZE: Adjust the MD size
ZOOM PRESET: Select zoom position to move when alarm is occurred
