BECKHOFF BK5000 - Handbuch (Seite 13)

Anhang
BK5000 11
Anhang
Module Name : BK__zzz
(zzz : KID, über HEX-Schalter eingestellt, nicht belegte Ziffern mit z=0
versehen)
Module Type
Obj.
Nr. Object Name Object
Type Class Access
Type User
Type Default
Priority
Group Default
Inhibit
Time Mux
Value
Mess.
Comp.
Nr. Message Comp.
Name
Message
Comp.
Data Type Error
Data
Type
1 #BK_AI2W0_zzzX Variable Basic Write-Only Server 1 0 - 1 Kanalnummer unsigned (16) -
2 #BK_AI2W1_zzzX Variable Basic Write-Only Client 1 0 - 1 Kanalnummer unsigned (16) -
- 2 Analogwert unsigned (16) -
3 #BK_AO2W0_zzzX Variable Basic Write-Only Server 1 0 - 1 Kanalnummer unsigned (16) -
- 2 Analogwert unsigned (16) -
4 #BK_AI4W0_zzzX Variable Basic Write-Only Server 1 0 - 1 Kanalnummer unsigned (16) -
5 #BK_AI4W1_zzzX Variable Basic Write-Only Client 1 0 - 1 Kanalnummer unsigned (16) -
- 2 Analogwert unsigned (32) -
6 #BK_AO4W0_zzzX Variable Basic Write-Only Server 1 0 - 1 Kanalnummer unsigned (16) -
- 2 Analogwert unsigned (32) -
7 #BK_DI1W0_zzzX Variable Basic Write-Only Server 1 0 - 1 Paketnummer unsigned (16) -
8 #BK_DI1W1_zzzX Variable Basic Write-Only Client 1 0 - 1 Paketnummer unsigned (16) -
- 2 Digitalwert 0 boolean -
- 3 Digitalwert 1 boolean -
- 4 Digitalwert 2 boolean -
- 5 Digitalwert 3 boolean -
- 6 Digitalwert 4 boolean -
- 7 Digitalwert 5 boolean -
- 8 Digitalwert 6 boolean -
- 9 Digitalwert 7 boolean -
9 #BK_DO1W0_zzzX Variable Basic Write-Only Server 1 0 - 1 Paketnummer unsigned (16) -
- 2 Digitalwert 1 boolean -
- 3 Digitalwert 2 boolean -
- 4 Digitalwert 3 boolean -
- 5 Digitalwert 4 boolean -
- 6 Digitalwert 5 boolean -
- 7 Digitalwert 6 boolean -
- 8 Digitalwert 7 boolean -
9 Digitalwert 8 boolean
10 #BK_ERREV_zzzX Event Uncon-
trolled - Server 1 0 - 1 K-Bus-Fehler 1 unsigned (16) -
K-Bus-Fehler 2 boolean
K-Bus-Fehler 3 boolean
K-Bus-Fehler 4 boolean
Canbus-Fehler 1 boolean
Canbus-Fehler 2 boolean
Canbus-Fehler 3 boolean
Canbus-Fehler 4 boolean
