Advanced Chipset Features
Kapitel: BIOS-Einstellungen
Beckhoff New Automation Technology CB3053
Seite 45
5.5 Advanced Chipset Features
Phoenix – AwardBIOS CMOS Setup Utility
Advanced Chipset Features
DRAM Timing Selectable
By SPD
Item Help
System BIOS Cacheable
[Enabled]
Video BIOS Cacheable
[Enabled]
** VGA Setting **
On-Chip Video Memory Size
[128MB]
On-Chip Frame Buffer Size
[ 8MB]
Current Configuration
DVO
Boot Type
[Auto]
LCD Panel Type
[640x480 generic]
Panel Scaling
[Auto]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü DRAM Timing Selectable
Optionen: keine
ü System BIOS Cacheable
Optionen: Enabled / Disabled
ü Video BIOS Cacheable
Optionen: Enabled / Disabled
ü On Chip Video Memory Size
Optionen: 256MB / 128MB
ü On Chip Frame Buffer Size
Optionen: 1MB / 4MB / 8MB
ü Current Configuration
Optionen: keine
ü Boot Type
Optionen: Auto / LVDS / DVI
ü LCD Panel Type
Optionen: 640x480 generic / 800x600 generic / 1024x768 generic / 640x480 NEC 8.4'' / 800x480
NEC 9'' / 1024x600 TMD 5.61'' / 1024x600 Samsung 4.8'' / 1024x768 Samsung 15'' /
1024x768 Sharp 7.2'' / 1280x800 Samsung 15.4
ü Panel Scaling
Optionen: Auto / Force / Off
