Integrated Peripherals
Kapitel: BIOS-Einstellungen
Beckhoff New Automation Technology CB3053
Seite 49
5.6.3 SuperIO Devices
Phoenix – AwardBIOS CMOS Setup Utility
SuperIO Device
Onboard Serial Port 1
[3F8/IRQ4]
Item Help
Onboard Serial Port 2
[2F8/IRQ3]
UART Mode Select
[Normal]
x RxD , TxD Active
Hi,Lo
x IR Transmission Delay
Enabled
x UR2 Duplex Mode
Half
x Use IR Pins
RxD2,TxD2
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü Onboard Serial Port 1
Optionen: Disabled / 3F8/IRQ4 / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Auto
ü Onboard Serial Port 2
Optionen: Disabled / 3F8/IRQ4 / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Auto
ü UART Mode Select
Optionen: IrDA / ASKIR / Normal
ü RxD , TxD Active
Optionen: Hi,Hi / Hi,Lo / Lo,Hi / Lo,Lo
ü IR Transmission Delay
Optionen: Enabled / Disabled
ü UR2 Duplex Mode
Optionen: Full / Half
ü Use IR Pins
Optionen: RxD2,TxD2 / IR-Rx2Tx2
