Guntermann & Drunck GmbH Operating Instructions
CATVision (MC)
page 39
6.2.2.5 Local Video (Dark-Switching)
Function according to
chapter 6.2.2.4 but related to the picture at the local
console (monitor at CATVision-CPU).
6.2.2.6 Permanent Access
Whilst your e. g. configuration you don´t want to be interrupted. Therefor the
remote console (CATVision-CON) as well as for the local console (CATVision-
CPU) has the possibility of activating a permanent access (hold function,
see
chapter 7.3 ).
If the permanent access is activated at one console by CTRL + Print the
computer access for this console is exclusive. If in the entries “Local Video”
and “Remote Video” (
see chapters 6.2.2.4 – 6.2.2.5 ) the setting is Switch Off
the monitors of the blocked consele are additionally switched dark.
The blocked station has access until the function is disabled by the same key
combination.
The function Permanent Access allows the following settings:
BOTH Both consoles can activate the permanent access
NONE No console can activate the permanent access
LOCAL Only
the local console (CATVision-CPU) can activate
the permanent access
REMOTE Only the remote console (CATVision-CON) can
activate the permanent access
The change in setting is done by moving the cursor with the mouse or keyboard
to the entry Permanent Access.
With
SPACE the selection is activated (toggle function)
For saving the settings and closing the menu press F1 .
