11 CV-Power-Expansion
By the CV-Power functionality (GPIO=General Purpose Input Output) the
CATVision system offers the possibility of transmitting electronic signals over
long distances.
A correct application for this is the remote control of
 RESET and
 switching of the ATX power supply
in a PC. With a simple slot-aperture insertion card the current key switches are
combined with the control signals of CATVision.
11.1 Scope of Delivery
For the connection at the CATVision-CPU

1 x CV power Slot card (ATX module) for the
installation in a PC

2 x 2pole connection cable-0,4 for the connection between
motherboard and CV power
(2-core jack/jack)

2 x 2pole connection cable-0,4 for the extension of the jack-jack cable
(2-core connector/jack)

1 x Power Cord-2 Connection cable for connecting the
CV power card with the CATVision
CPU (3pole connector on RJ9 plug)
For the connection at the CATVision-CON

1 x 3-pole cable jack for the connection at the
key switch connection cable
