Configuration
G&D DVIMUX8-OSD-USB · 40
English
Transmitting keyboard and/or mouse signals to all computers
In the default settings of the KVM switch, the console keyboard and mouse signals
are transmitted only to the active computer.
After you enable the Broadcast mode (see page 19), you can transmit the keyboard
and/or mouse signals to up to eight channels.
You can use the Broadcast function, for example, to send key combinations to close
all open windows at all computers or to reset all copmuters by using the keyboard.
You need to configure the Broadcast mode before you can use it.
How to configure the Broadcast mode
1. Press
Ctrl+Num (standard) to open the On-Screen Display.
2. Press F1 to open the menu.
3. Use the Arrow keys to select Console Setup , and press Enter .
4. Use the Arrow keys to select Broadcast , and press Space to select one of the follow-
ing options:
5. Press F1 to save your settings.
NOTE: Transmitting keyboard and/or mouse signals to the computers of a slave
switch is not supported.
Off: The Broadcast mode cannot be enabled.
Keyboard: If the Broadcast mode is active, any keyboard inputs made
by the user are transmitted to all computers.
Key and Mouse: If the Broadcast mode is active, any keyboard inputs and
mouse gestures made by the user are transmitted to all
computers.
NOTE: When transmitting mouse signals to all computers, please keep in mind
that the mouse cursors of the different computers might have different original
positions.
