Setup menu
9 · MultiPower-6
Displaying status information
How to display status information in the terminal emulator:
1. Start the terminal emulator.
2. Load the connection settings of the setup menu and establish the connection.
3. Press
R
in the terminal emulator.
4. Use the
Arrow
or
Arrow
keys to select
Show Firmware Info
,
Show Temp Info
,
Show Load
Info
or
Show Power Out Info
and press
Enter
.
The different menus provide the following information:
5. Press
Q
to return to the main menu.
6. Repeat steps 4 and 5 to view more status information.
FIRMWARE INFO
FW:
Version number of installed firmware
TEMP INFO
Temp1:
Temperature (°C) - first sensor
Temp2:
Temperature (°C) - second sensor
Fan1:
Rotations per minute - first fan
Fan2:
Rotations per minute - second fan
LOAD INFO
This menu shows information about the load of the »Main Power« and »Redundant Power«
power packs.
The values are subject to component and measuring tolerances.
U:
Voltage (Volt)
I:
Current (Ampere)
P:
Power (Watt)
POWER OUT INFO
This menu shows information about the different »Power Out« sockets.
Switched:
On:
output is enabled
Off:
output is disabled
Power:
On:
voltage available
Off:
no voltage available
