3
7. Installation of the Camera
The bracket can be installed to either the top or bottom of the
camera as desired. From changing the position of the camera
mounting bracket, you should always reuse the screws that
have been removed.
NOTE: When using a camera mounting bracket, select
a location that is strong enough to bear the full
weight of the camera and the mounting bracket
hold long periods, and install the camera
mounting bracket securely.
Tele (Up) button: Zoom in, Tele (Moves the
cursor upwards. Use this button to select an
item or adjust the parameters.)
Wide (Down) button: Zoom out, Wide (Mo-
ves the cursor downwards. Use this button to
select an item or adjust the parameters.)
Far (Right) button: Adjust focus in Manual
Mode(Moves the cursor to the right. Use this
button to select or adjust the parameters of
the selected item. The parameter changes
each time this button is pressed.)
Near (Left) button: Adjust focus in Manual
Mode Moves the cursor to the left. Use this
button to select or adjust the parameters of
the selected item. The parameter changes
each time this button is pressed.)
Set button: Executes selections and displays
a submenu for an item with the mark.
8. Menu Operation
This camera utilizes an on-screen user MENU.
To set items on the menu, use the following buttons
on the side panel.
