5
8.3 EXPOSURE
• MODE: Adjust MODE
AUTO / IRIS.P / SHUT.P / MANUAL
• AGC: Select Auto Gain Control
OFF / ON
• SHUT SPEED: Can be set in SHUT.P or MANUAL mode
AUTO / /30(5),/60(50),/0(00),/40,/500,/000,/000,/4000,/8000, /6000, /30000,
/60000 sec
• IRIS: Iris level can be set in IRIS.P or MANUAL mode
AUTO / MANUAL (0 ~ 0)
• DSS: Select maximum DSS (Digital Slow Shutter)
OFF / x, x3, x4
• FLICKERLESS: Select Flickerless mode
OFF / ON (remove screen flicker)
• BRIGHTNESS: Adjust brightness level
0 (dark) ~ 0 (bright) steps
• WDR/BLC: Select WDR (Wide Dynamic Range) or BLC (Back Light Compensation)
WDR WEIGHT: Adjust WDR level (0 ~ 3)
BLC AREA: Control BLC area according to light condition.
POS-X: Adjust the window X-Axis position
POS-Y: Adjust the window Y-Axis position
SIZ-X: Adjust the window X-Axis size
SIZ-Y: Adjust the window Y-Axis size
NOTE: When WDR is ON, ACE and DEFOG function can not turn on.
• DAY&NIGHT: Select Day&Night
AUTO / DAY / NIGHT / EXT Delay: 0 ~ 55 seconds
BURST: OFF / ON
THRS: (LOW / MIDDLE / HIGH)
According to daytime, nighttime setting the levels of transition sets to no
changes when it is dark at, higher the step it is set to
GAP: LOW / MIDDLE / HIGH
This setting adjusts the margin of change from the setting of light to dark /
daytime to nighttime and dark to light / nighttime to daytime. If this setting is
too low then fluctuation may occur.
