Multi-Contact MA025 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
DBT-IB16NS 15.5270 IB16BV-NS-A 14.2037
DST16NS 15.5272 IS16BV-NS 14.2034
MA025 (de_en)
Montageanleitung MA025 (de_en)
Assembly instructions
Rundsteckverbinder IB16BV-NS-A, IS16BV-NS
mit Bajonnetverriegelung Panel receptacle ID/B16BV-NS-A, ID/S16BV-NS
with bayonet locking
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
1. Steckverbindermontage in Stromschiene .............................3
2. Steckverbindermontage in Fronttafel ....................................4
Montage der Anschlussleitung .................................................5
3. Montage des Mikroschalters (IB16BV-NS) ............................5
4. Montage des Mikroschalters (IS16BV-NS) ............................5
Funktionskontrolle der Mikroschalter ........................................6
5. Montieren der Schutzkappe ..................................................6
Kodierung ..................................................................................6
Wichtige Hinweise ....................................................................7 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
1. Connector assembly into busbar ...........................................3
2. Connector assembly in front panel ........................................4
Cable connection .......................................................................5
3. Installation of microswitch (IB16BV-NS) ...............................5
4. Installation of microswitch (IS16BV-NS) ................................5
Functional check of microswitches ...........................................6
5. Mounting of protective cap ...................................................6
Coding .......................................................................................6
Important notice ........................................................................7
MS-B16BV-NS 14.0102
(für/for 14.2036)
MS-IS16BV-NS 14.0101
(für/for 14.2034)
