Multi-Contact MA018 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 4
KBT30BV/...
KST30BV/...
MA018 (de_en)
Montageanleitung MA018 (de_en)
Assembly instructions
KBT30BV (50...400)
KST30BV (50...400) KBT30BV (50...400)
KST30BV (50...400)
Inhalt
Sicherheitshinweise....................................................................2
Teile vorbereiten ........................................................................3
Vorbereitung der Leitung ...........................................................3
Crimpen der Kontakte ................................................................3
Buchsenmontage ......................................................................4
Steckermontage ........................................................................4
Prinzip der Bajonettverriegelung ...............................................4 Content
Safety Instructions ......................................................................2
Preparation of parts ...................................................................3
Preparation of the cable ............................................................3
Crimping the contacts ...............................................................3
Socket assembly........................................................................4
Plug assembly ...........................................................................4
Bayonet locking system ............................................................4
Verdrehschutzbolzen
Anti-twist pin
Gehäusevorderteil
Front insulation Buchseneinsatz
Socket insert Gehäuserückteil
Back insulation
Gehäusevorderteil
Front insulation Gehäuserückteil
Back insulation Steckerstift
Plug pin
