Multi-Contact MA030 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
FSA20...
MA030 (de_en)
Montageanleitung MA030 (de_en)
Assembly instructions
Flachschienenabgriff
FSA20K..., FSA20A... zum Selbstkonfektionieren Flact contact clamp
FSA20K..., FSA20A... for self assembly
Inhalt
Sicherheitshinweise....................................................................2
Erforderliches Werkzeug ...........................................................3
Leitungskonfektionierung ..........................................................4
Demontage ................................................................................7
Notizen ......................................................................................8 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Wire assembly ...........................................................................4
Dismantling ...............................................................................7
Notes .........................................................................................8
PT-Schraube (für Thermoplast)
PT-Screw (for thermoplast)
KA3,5x35
Schwerspannstift
Heavy type dowel pin
DIN1481 Ø4x32
Schrumpfschlauch (mit Klebstoff)
Shrink sleeve (with adhesive)
Crimphülse
Crimp sleeve
A-P...
Isolation
Insulation
Isolation-Halbschalen
Insulation shells
