Multi-Contact MA049 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
KBT10BV-AX/M...-C... VR10BV
MA049 (de_en)
Montageanleitung MA049 (de_en)
Assembly instructions
Verriegelungsring VR10BV für Kupplungsbuchsen
KBT10BV-AX/M...-C... Locking ring VR10BV for socket couplers
KBT10BV-AX/M...-C...
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Montage des Verriegelungsrings...............................................3
Steckvorgang mit Verriegelungsring .........................................5
Trennvorgang mit Verriegelungsring .........................................5
Kodierung ..................................................................................6 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Installation of locking ring .........................................................3
Plugging procedure with locking ring .......................................5
Unplugging procedure with locking ring ...................................5
Coding .......................................................................................6
