Multi-Contact MA043 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 12
MA043 (de_en)
Montageanleitung MA043 (de_en)
Assembly instructions
Montage und Demontage des Kontakteinsatzes
für KBT16BV-NS/M... und KST16BV-NS/M... mit
dem Werkzeug WKZ16BV-NS-A Assembly and dismantling of contact inserts for
KBT16BV-NS/M... and KST16BV-NS/M... with the
tool WKZ16BV-NS-A
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Demontage des Werkzeugs ......................................................3
Montage des Werkzeugs ...........................................................4
Demontage des Kontakteinsatzes für KST16BV ........................4
Crimphülse demontieren ...........................................................5
Montage des Kontakteinsatzes für KST16BV ............................6
Demontage des Kontakteinsatzes für KBT16BV ........................7
Montage des Kontakteinsatzes für KBT16BV ............................8
Wichtige Hinweise ..................................................................10 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Dismantling the tool ..................................................................3
Assembling the tool ..................................................................4
Removing the contact insert in KST16BV .................................4
Removing the crimping sleeve ..................................................5
Installing the contact insert for KST16BV ..................................6
Removing the contact insert for KBT16BV ................................7
Installing the contact insert for KBT16BV ..................................8
Important notice ......................................................................10
KST-Isolation
KST insulation
KBT-Isolation
KBT insulation
Kontakteinsatz (Stecker)
Contact insert (plug)
Kontakteinsatz (Buchse)
Contact insert (socket)
