Multi-Contact MA021 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
BL2N - BL6N BL8N - BL20N BL25N - BL50N BL60N - BL100N
See Tab. 1 for dimensions, page 5/8
MA021 (de_en)
Montageanleitung MA021 (de_en)
Assembly instructions
MC Kontaktbuchse BL... mit Aussengewinde
zum Einschrauben oder Verschrauben in Kon-
taktblöcke bzw. Stromschienen MC Contact socket BL... with external thread to
screw into contact blocks and busbars
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Montage in Kontaktblock mit Innengewinde ............................3
Vorbereiten des Kontaktblockes ................................................3
Vorbereiten der Buchse .............................................................3
Montage der Buchse .................................................................3
Montage in Stromschienen mit Durchgangsbohrung ...............3
Vorbereitung der Stromschiene.................................................3
Vorbereiten der Buchse .............................................................4
Montage der Buchse .................................................................4
Adapter für Drehmomentschlüssel ...........................................6 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Assembly in contact block with internal thread ........................3
Preparation of contacts block ....................................................3
Socket preparation ....................................................................3
Socket mounting .......................................................................3
Installation in busbars with through hole ..................................3
Busbar preparation ....................................................................3
Socket preparation ....................................................................4
Socket mounting .......................................................................4
Adapters for torque wrench ......................................................6
Masse siehe Tab. 1, Seite 5/8
