Multi-Contact MA064 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
MA064 (de_en)
Montageanleitung MA064 (de_en)
Assembly instructions
Montage und Demontage des Kontakteinsatzes
für KBT16BV-AX/M... und KST16BV-AX/M... mit
dem Werkzeug WKZ16BV-NS-A Assembly and dismantling of contact inserts for
KBT16BV-AX/M... and KST16BV-AX/M... with the
tool WKZ16BV-NS-A
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Demontage des Werkzeugs ......................................................3
Montage des Werkzeugs ...........................................................3
Demontage des Kontakteinsatzes für KST16BV ........................4
Demontage des Kontakteinsatzes für KBT16BV ........................5 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Dismantling the tool ..................................................................3
Assembling the tool ..................................................................3
Removing the contact insert in KST16BV .................................4
Removing the contact insert in KBT16BV .................................5
KBT-Isolation
KBT insulation
KST-Isolation
KST insulation
Kontakteinsatz (Buchse)
Contact insert (socket)
Kontakteinsatz (Stecker)
Contact insert (plug)
