Multi-Contact MA007 - Handbuch

Advanced Contact Technology
www.multi-contact.com 1 / 8
KST6AR-W-N/10
KST6AR-W-N/16
KST6AR-W-N/25
KBT6AR-W-N/10-S
KBT6AR-W-N/16-S
KBT6AR-W-N/25-S
KST6AR-W-N/25-L
KBT6AR-W-N/25-S-L
for cables with outer-Ø up to 10,5mm
for cable with outer-Ø over 10,5mm
K-SCH6-W-N/10 AG
17.1001
K-SCH6-W-N/16 AG
17.1002
K-SCH6-W-N/25 AG
17.1003
U/M6 AG
08.0304
MU0,5D/M6 AG
08.0004 T6-W-N
15.5167-21 T6N
15.5001-*
K-SCH6-W-N/25 AG
17.1003
RH25-16
05.5108
RH16-10
05.5112
U/M6 AG
08.0304
MU0,5D/M6 AG
08.0004 T6-W-N
15.5167-21 T6L
15.5006-21
MA007 (de_en)
Montageanleitung MA007 (de_en)
Assembly instructions
Winkelstecker KST6AR-W-N/...
Winkelbuchse KBT6AR-W-N/...-S Right angle plug KST6AR-W-N/...
Right angle socket KBT6AR-W-N/...-S
Inhalt
Sicherheitshinweise....................................................................2
Notwendiges Werkzeug ............................................................3
Vorbereitung der Tülle ...............................................................3
Vorbereitung der Leitung ...........................................................3
Konfektionierung .......................................................................3
Kabelschuhmontage ..................................................................4
Endmontage ..............................................................................4
MC Arretierungssystem (AR-System) .......................................5
Steckverbindung arretieren .......................................................6
Steckverbindung lösen ..............................................................7 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Sleeve preparation .....................................................................3
Preparation of the cable ............................................................3
Wire assembly ...........................................................................3
Assembly of the cable lug .........................................................4
Plug assembly ...........................................................................4
MC Locking system (AR-System) ..............................................5
Locking the plug connection .....................................................6
Releasing the plug connection ..................................................7
für Leitungen mit Aussen-Ø unter 10,5mm
für Leitungen mit Aussen-Ø über 10,5mm
S6AR-N
04.0201
Stift, komplett
Plug, complete
B6AR-NS
01.0200
Buchse, komplett
Socket, complete
S6AR-N
04.0201
Stift, komplett
Plug, complete
B6AR-NS
01.0200
Buchse, komplett
Socket, complete
