15

STANDARD-KOMPONENTEN

MAX200

(Maschinenbrenner) Betriebsanleitung

6-9

Position

Teilenummer Beschreibung

Kennzeichnung

Menge

*

,

**

P/O Power Supply Assy

1

029359

Linkboard SA (240/480V models only)

LB1

1

029315

P/O Shield Gas Supply SA

2

005233

Switch, pressure, 0-90 psi

PS2

1

3

006037

Valve, solenoid

V4

1

*

,

**

P/O Power Supply Assy

4

008551

Fuse, 7.5 Amp, 600V

F1

1

5

008551

Fuse, 7.5 Amp, 600V

F2

1

6

008073

Terminal strip (8)

TB4

1

7

008134

Terminal strip (16)

TB3

1

8

003092

Contactor, 90 Amp, 3-pole, 24 VAC

CON1

1

9

003093

Switch, aux contactor

SW2

1

10

029316

Terminal block, power SA

TB1

1

11

014080

Inductor, 4 mh, 100 Amps, DC

L1

1

12

014078

Trans, 30 kw, 240/480V, 3Ø, 60 Hz

T2

1

014088

Trans, 30 kw, 220/380/400/415V, 3Ø, 50 Hz

T2

1

014082

Trans, 30 kw, 600V, 3Ø, 60 Hz

T2

1

014097

Trans, 30 kw, 208V, 3Ø, 60 Hz

T2

1

014100

Trans, 30 kw, 200V, 3Ø, 60 Hz

T2

1

029314

P/O Plasma Gas Supply SA

13
14
15

(Siehe Abb. 6-3.)

16
17
18

129118

Chopper SA, CH130 CE/LVD

CH1

1

005199

Switch, temperature 82° C

TSW1

1

*

,

**

P/O Power Supply Assy

19

014079

Trans, control, 208/240/480V, 1Ø, 60 Hz

T1

1

014081

Trans, control, 220/380/400/415V, 3Ø, 50 Hz

T1

1

014083

Trans, control, 600V, 3Ø, 60 Hz

T1

1

014101

Trans, control, 200V, 3Ø, 60 Hz

T1

1

20

041534

PCB, power distribution

PCB6

1

008322

Fuse, Amp., 250 VAC

1

* Stromquellen mit THC – 073020, 073021, 073022, 073023, 073024 and 07321 3 (CE)

** Stromquellen ohne THC – 073002, 073003, 073004, 073005, 073026 and 073200 (CE)
