15
STANDARD-KOMPONENTEN
MAX200 (Maschinenbrenner) Betriebsanleitung 6-25
Maschinenbrenner-Pakete (fortz.)
Siehe Abbildung 6-10
Position Teilenummer Beschreibung Menge
028383 Shield Torch Lead, 25 Ft. 1
1 023326 Lead Pilot, Shield Gas, 25 Ft. (blue) 1
2 024194 Lead, Plasma Gas, 25 Ft. (red) 1
3 024192 Lead, Cap Sensor, 25 Ft. (gray) 1
4 023013 Cable, Water Cooled, 25 Ft. (blue- red band) 1
5 023013 Cable, Water Cooled, 25 Ft. (blue- green band) 1
6 020536 Lead Insulator, 9/16" ID x 2-1/2" 1
7 046026 Tubing, 1-1/2" ID Shrink Black 1
8 046061 2" ID Tinned Braid 1
9 027015 Ring Compress, Shield Torch Lead 1
10 004080 Collar, Shield Torch Leads 1
11 015090 Clamp, Hose, 1-5/16 - 2-1/4" 1
028457 Shield Torch Lead, 30 Ft. 1
1 023432 Lead Pilot, Shield Gas, 30 Ft. (blue) 1
2 024229 Lead, Plasma Gas, 30 Ft. (red) 1
3 024224 Lead, Cap Sensor, 30 Ft. (gray) 1
4 023014 Cable, Water Cooled, 30 Ft. (blue- red band) 1
5 023014 Cable, Water Cooled, 30 Ft. (blue- green band) 1
6 020536 Lead Insulator, 9/16" ID x 2-1/2" 1
7 046026 Tubing, 1-1/2" ID Shrink Black 1
8 046061 2" ID Tinned Braid 1
9 027015 Ring Compress, Shield Torch Lead 1
10 004080 Collar, Shield Torch Leads 1
11 015090 Clamp, Hose, 1-5/16 - 2-1/4 1
028458 Shield Torch Lead, 35 Ft. 1
1 023433 Lead Pilot, Shield Gas, 35 Ft. (blue) 1
2 024218 Lead, Plasma Gas, 35 Ft. (red) 1
3 024225 Lead, Cap Sensor, 35 Ft. (gray) 1
4 023015 Cable, Water Cooled, 35 Ft. (blue- red band) 1
5 023015 Cable, Water Cooled, 35 Ft. (blue- green band) 1
6 020536 Lead Insulator, 9/16" ID x 2-1/2" 1
7 046026 Tubing, 1-1/2" ID Shrink Black 1
8 046061 2" ID Tinned Braid 1
9 027015 Ring Compress, Shield Torch Lead 1
10 004080 Collar, Shield Torch Leads 1
11 015090 Clamp, Hose, 1-5/16 - 2-1/4 1
