15
STANDARD-KOMPONENTEN
MAX200
(Maschinenbrenner) Betriebsanleitung
6-13
Position
Teilenummer Beschreibung
Kennzeichnung
Menge
*
,
**
P/O Power Supply Assy
1
008317
Fuse, semiconductor, 125 Amp, 250 V
F3
1
2
008317
Fuse, semiconductor, 125 Amp, 250 V
F4
1
3
129118
Chopper SA, CH130 CE/LVD
CH2
1
005199
Switch, temperature 82° C
TSW2
1
*
,
**
P/O Power Supply Assy
4
014078
Trans, 30 kw, 240/480V, 3Ø, 60 Hz
T2
1
014088
Trans, 30 kw, 220/380/400/415V, 3Ø, 50 Hz
T2
1
014082
Trans, 30 kw, 600V, 3Ø, 60 Hz
T2
1
014097
Trans, 30 kw, 208V, 3Ø, 60 Hz
T2
1
014100
Trans, 30 kw, 200V, 3Ø, 60 Hz
T2
1
5
014080
Inductor, 4 mh, 100 Amps, DC
L2
1
6
009684
Resistor, 4 Ohm, 420 W
R6
2
7
009015
Resistor, 10 K Ohm, 10 W
R5
1
8
009438
Resistor, 5 Ohm, 50 W
R4
1
9
009506
Capacitor, elec, 250 uf, 350 VDC
C9
1
10
003021
Relay, 120 VAC
CR1
1
029314
P/O Plasma Gas Supply SA
11
005228
Switch, pressure, SPDT, 0-15 psi
PS3
1
*
,
**
P/O Power Supply Assy
12
029317
Transformer, High Voltage SA
T5
1
13
008479
Terminal strip, quick connect
TB2
1
14
029312
High Freq Input/Output Panel SA
1
15
009350
Assembly, spark gap
SG1
1
16
009349
Assembly, coil, high frequency
T6
1
17
041145
PCB, input/output
PCB5
1
18
029202
Sensor, current
CS1
1
* Stromquellen mit THC – 073020, 073021, 073022, 073023, 073024 and 073213 (CE)
** Stromquellen ohne THC – 073002, 073003, 073004, 073005, 073026 and 073200 (CE)
