15
STANDARD-KOMPONENTEN
MAX200
(Maschinenbrenner) Betriebsanleitung
6-11
Position
Teilenummer Beschreibung
Kennzeichnung
Menge
1
129118
Chopper SA, CH130 CE/LVD
CH2
1
005199
Switch, temperature 82° C
TSW2
1
*
,
**
P/O Power Supply Assy
005102
Thermostat, 160°C, 6 Amp
TS1
1
2
014078
Trans, 30 kw, 240/480V, 3Ø, 60 Hz
T2
1
014088
Trans, 30 kw, 220/380/400/415V, 3Ø, 50 Hz
T2
1
014082
Trans, 30 kw, 600V, 3Ø, 60 Hz
T2
1
014097
Trans, 30 kw, 208V, 3Ø, 60 Hz
T2
1
014100
Trans, 30 kw, 200V, 3Ø, 60 Hz
T2
1
3
014080
Inductor, 4 mh, 100 Amps, DC
L2
1
4
007022
Shunt, 100 Amp, 100 mv
R2
1
5
007022
Shunt, 100 Amp, 100 mv
R1
1
6
007024
Shunt, 200 Amp, 100 mv
R3
1
7
008317
Fuse, semiconductor, 125 Amp, 250 V
F4
1
8
008317
Fuse, semiconductor, 125 Amp, 250 V
F3
1
128236
Phase loss detection upgrade kit
1
* Stromquellen mit THC – 073020, 073021, 073022, 073023, 073024 and 073213 (CE)
** Stromquellen ohne THC – 073002, 073003, 073004, 073005, 073026 and 073200 (CE)
