HEIDENHAIN iTNC 530
339
9.8 Zusätzlic
he F
unktionen
Schaltendes Tastsystem TS, 350
10
-
Tastsystem-Achse
11
-
Wirksamer Kugelradius
12
-
Wirksame Länge
13
-
Radius Einstellring
14
1
Mittenversatz Hauptachse
2
Mittenversatz Nebenachse
15
-
Richtung des Mittenversatzes gegenüber 0°-Stellung
Tischtastsystem TT
20
1
Mittelpunkt X-Achse (REF-System
2
Mittelpunkt Y-Achse (REF-System)
3
Mittelpunkt Z-Achse (REF-System)
21
-
Teller-Radius
Letzter Antastpunkt TCH
PROBE- Zyklus 0 oder letzter
Antastpunkt aus Betriebsart
Manuell, 360
1
1 bis 9
Position im aktiven Koordinaten-System Achse 1 bis 9
2
1 bis 9
Position im REF-System Achse 1 bis 9
Gruppen-Name, ID-Nr.
Nummer
Index
Bedeutung
