Einbau
Fortsetzung
Legende
1
Vollautomatischer Schnellentlüfter
2
Rücklaufventil (Kugelhahn DN 10 L, PN 500)
3
Ablaufleitung DN 12
4
Normblende
5
Hauptmaschine, Hilfsdiesel, Ölkühler etc.
6
Entleerungsventil (Kugelhahn DN 12 L, PN 500)
7
Zulaufleitung DN 14
8
Zulaufventil (Kugelhahn DN 12 L, PN 500)
9
Messgefäß ORGS 11-2
