38
4.2
FACTORY DEFAULTS - Set to factory default
4.
4 DMX ADDRESS - DMX addressing
Change the DMX address directly by means of the keys "UP" and "DOWN". Confirm and
store it by pressing key "ENTER". The DMX address can also be changed in the menu
DMX ADDRESS.
To set back the A12 to factory setting choose menu point FACTORY DEFAULT, LOAD
DEFAULTS. After confirming SURE ? in the display, the personal settings of the A12 will
be set back to factory default.
If the white balance was adjusted before, it will be not affected by the set back to factory
default.
4.5 PERSONALITY
DMX MODE
The A12 offers 5 different operating modes (see DMX protocol page 25). For using the full
range of DMX channels use the Standard 8 BIT or Standard 16 BIT modes. Switching 8
BIT to 16 BIT allows 16 BIT access to the RGBW channels. In order to operate the A12
with less DMX-channels the DMX Mode can be set to COMPRESSED MODE. In this
mode the channels colour macro, pan/tilt speed, effect speed and blackout move are
deactivated. With extended mode (E8) each LED string can be controlled seperately.
PAN/TILT
sets pan and tilt to 8 bit or 16 bit control resolution. The default setting is
16 bit. If this fine resolution is not required, you can set to 8 bit for quicker operation off
pan/tilt values. The
commands invert the direction of pan
and tilt. The PAN/TILT SWAP command sets pan commands to tilt and vice versa.
RESOLUTION
PAN INVERS and TILT INVERS
CURVES
Dimming curves can be adjusted for the dimmer channel and the RGBW channels. There
is a square-law curve for finer control at low intensity and coarser control at high intensity
and a linear-law curve available.
SHORTEST DISTANCE
This setting is only for the colour wheel channel. On ON (default) it always take the
shortest route from one colour to another in order to simulate a physical colour wheel. On
OFF it routes only from white to cyan and backwards.
DMX INPUT MODE
The A12 provides an embedded radio-DMX receiver. The receiver works together with the
JB-Lighting Wireless TRX transmitter. To enable the A12 to receive radio-DMX change the
menu from WIRED (factory default) to WIRED/WIRELESS. The fixture needs to be logged
-in to the Wireless TRX transmitter. To log-in press the „Start“ button (see also manual
Wireless TRX). The radio channel is displayed when the A12 is logged. The main display
will show the intensity of the incoming signal. If the A12 is connected either via DMX cable
and radio-DMX, the cable signal has priority.
4.3
USER DEFAULTS - Set to user defaults
If the personal settings are done in the PERSONALITY menu, the user can save and
reload it in the USER DEFAULTS menu. To make sure that the personnal settings are not
changed quickly on a stage, the save progress is locked with the password „JB-LIGHTING“.
