5.2 FIXTURE MODE „Extended“
The A12 offers 8 different channel options. With PERSONALITY -> FIXTURE MODE (selection
between Standard or Extended mode) and after with DMX MODE (selection of S8, S16, C8,
C16 and E8 respectively M1, M2, M3) you can select the different channel options. The
selected mode will be displayed in the main menu.
Mode 1 (M1) Mode 2 (M2) Mode 3 (M3)
Channel 1 Pan Pan Pan
Channel 2 Pan fine Pan fine Pan fine
Channel 3 Tilt Tilt Tilt
Channel 4 Tilt fine Tilt fine Tilt fine
Channel 5 Control Control Control
Channel 6 Shutter Shutter Shutter
Channel 7 Dimmer Dimmer Dimmer
Channel 8 Zoom Zoom Zoom
Channel 9 Mapping Mapping Mapping
Channel 10 Pattern mode Pattern mode Pattern mode
Channel 11 Pattern Pattern Pattern
Channel 12 Pattern speed Pattern speed Pattern speed
Channel 13 Color spread Color spread Color spread
Channel 14 Sparkle Sparkle Sparkle
Channel 15 Sparkle speed Sparkle speed Sparkle speed
Channel 16 CTC CTC CTC
Channel 17 Fixed Colors Fixed Colors Fixed Colors
Channel 18 Pan/Tilt speed Pan/Tilt speed Pan/Tilt speed
Channel 19 Effect speed Effekt speed Effekt speed
Channel 20 Segment shutter / blackout
move Segment shutter / blackout
move Segment shutter / blackout
move
Channel 21 Red Red Red
Channel 22 Green Red fine Green
Channel 23 Blue Green Blue
Channel 24 White Green fine White
Channel 25 Red Blue
Channel 26 Green Blue fine
Channel 27 Blue White
Channel 28 White White fine
Channel 29 Red Red
Channel 30 Green Red fine
Channel 31 Blue Green
Channel 32 White Green fine
Channel 33 Blue
Channel 34 Blue fine
Channel 35 White
Channel 36 White fine
Channel 37 Red
Channel 38 Red fine
Channel 39 Green
Channel 40 Green fine
Channel 41 Blue
Channel 42 Blue fine
Channel 43 White
Channel 44 White fine
Glow
}
Main
}
Pattern
}
Glow
}
Main
Pattern
}
}
